Suntec |
 |
|
| |
 KLEINER LESTUNGSBEREICH |
|
| |
 |
|
|
 AN |
|
Pump with a combination pressure regulator and piston cut-off valve.
Pressure ranges : 7 - 14 / 10 - 20 bars.
Flow range @ 2850 rpm, 5 cSt, 10 bars :
40 - 130 l/h. |
|
|
|
| |
| |
 |
|
|
| AS |
|
Pump with integral by-pass solenoid valve which controls the combination pressure regulator and piston cut-off valve (according to EN 264).
Pressure ranges : 7 - 14 / 10 - 15 bars.
Flow range @ 2850 rpm, 5 cSt, 10 bars :
40 - 80 l/h. |
|
|
|
| |
| |
 |
|
|
| AP |
|
Two steps basic model with two adjustable pressure ranges and one nozzle outlet.
Pressure ranges :
low mode : 8 - 15 bars,
high mode : 12 - 25 bars.
Flow range @ 2850 rpm, 5 cSt, 10 bars :
40 - 130 l/h. |
|
|
|
| |
| MITTERER LEISTUNGSBEREICH |
|
| |
 |
|
|
| J |
|
Sought after traditional engineering, this unit for medium capacity light oil burners incorporates a combination pressure regulator and cut-off valve.
Viscosity range : 2,8 - 200 cSt.
Pressure ranges : 10 - 21/ 10 - 30 bars.
Flow range @ 2850 rpm, 5 cSt, 10 bars :
170 - 330 l/h. |
|
|
|
| |
| |
 |
|
|
| E |
|
pump is renowned throughout the world for medium capacity industrial heavy oil applications. E 1069 high temperature version with preheater location is specially designed for easier cold starting and improved longevity.
Pressure range : 14 - 30 bars.
Flow range @ 2850 rpm, 20 cSt, 20 bars :
170 - 360 l/h. |
|
|
|
| |
| GROSSER LEISTUGSBERICH |
|
| |
 |
|
|
| TA |
|
This high technology fuel unit adapted for the rigours of industrial applications incorporates an integrated pressure regulator and a preheater location.
Pressure range : 40 bars max.
(except TA5 : 30 bars max)
Flow range @ 2850 rpm, 20 cSt, 20 bars :
500 - 1350 l/h. |
|
|
|
| |
| |
 |
|
|
| T |
|
Same concept as the TA pump, with higher capacity. The pressure regulation is assured by the seperate TV valve.
Pressure range : 40 bars max.
(except T5 : 30 bars max)
Flow range @ 2850 rpm, 20 cSt, 20 bars :
1380 - 3900 l/h. |
|
|
|
| |
|
